HERMEQ NorwaySteel Wall Pedestrian Door Panel
Product Highlights
- Flush fit access panel - Securely integrates with SteelWall hoarding panels for smooth site access.
- Built for durability - Galvanised and powder coated finish with reinforced steel cladding.
- Versatile compatibility - Works with all standard steel fence panels and hoarding systems.
SKU SW0872
Quickest Available Delivery: Quickest Available Delivery: 10 Day Delivery
Constructed from 0.75mm thick profiled steel with dual overlapped cladding sheets, the panel is both visually sleek and exceptionally robust. The outer frame is reinforced using channel supports and anti-rattle lips to maintain quiet, vibration-resistant operation during high-traffic usage. The cladding is secured with Tek screws and spot welding to prevent panel fatigue or detachment over time.
Key Benefits:
- Integrated door design - Built directly into a SteelWall panel for maximum site efficiency.
- Dual cladding system - Overlapping sheets with rivet connection for enhanced strength.
- Graffiti deterrent - Profiled steel surface resists stickers and vandalism for a clean finish.
- Multiple finishes - Choose from galvanised, painted or powder coated variants.
- In-ground or ballast options - Flexible installation for various site setups.
This panel is especially useful on projects that need a consistent look across all access points while preserving the security and stability of the perimeter. The flush fit ensures there are no large gaps, protecting pedestrians and keeping unauthorised personnel out. With quick deployment and minimal maintenance, it outperforms timber or ad hoc solutions.
HERMEQ stock a wide-range of Steel Site Hoarding, Temporary Fencing, Permanent Fencing & Road Barriers conforming to all required safety specifications and regulations.
Need any help? Contact HERMEQ Today.
Contact our team via phone 0800 043 2520, email sales@hermeq.com or use our live chat feature between 8:00am & 17:00pm for help discovering our range.
Applications:
- Personnel access points in secure site compounds or high-value construction areas.
- Entrance and egress along extended steel hoarding runs.
- Public-facing projects where visual impact and safety are crucial.
- Site perimeters in urban settings requiring anti-vandal and flush-finish features.
Each unit weighs between 30–40kg depending on the chosen height (2.0m or 2.4m) and finish (galvanised, painted or powder coated). The panel is reinforced using 43mm x 35mm channel steel with a rear lip to support cladding and prevent rattling.
It connects using the same T section posts as standard SteelWall panels, meaning no additional hardware or installation time is required. By maintaining consistency across access and security infrastructure, this unit keeps your build zone efficient, compliant, and secure throughout the project timeline.
Width: 2.1 meters
Height: 2.0 meters / 2.4 meters
Weight: 30kg / 40kg
Finish: Galvanised / Painted (one side) / Powder Coated (one side)
0.75mm thick profiled steel cladding - two sheets overlapped in the middle and secured together with two rivets
Tek screws and spot welding secure the steel cladding to the outer frame
Channel 43mm x 35mm x 1.2mm top & bottom (8mm lip on rear to hold cladding in place and prevent rattling)
What type of fencing should I use?
That depends on the project’s location and visibility. In populated or high-risk areas, two-metre-high mesh fencing or hoarding panels are usually recommended.
What makes steel hoarding more secure than timber fencing?
Steel hoarding is wind-resistant and vandal-deterrent. Timber fencing is more prone to collapse or degradation, especially in poor weather conditions.
Why choose a SteelWall door panel?
It provides a seamless, professional access point that’s secure, weatherproof, and integrates fully with your existing SteelWall system.
