Palisade Railway – Corner Post

Product Highlights

  • Corner transition post – Designed for changes in fencing direction or angled boundaries.
  • Certified RSJ steel – Built to NR/L2/TRK/5100/1/WP rail specifications.
  • Multiple heights – Available in 1.8m or 2.4m, galvanised or powder coated.

SKU PA344277

HERMEQ’s Network Rail spec corner posts are essential for secure fencing transitions around boundary changes or angles. Manufactured from robust RSJ steel and offered in 1.8m or 2.4m heights. Available in galvanised or powder-coated finishes. Compatible with W-section pales and RSA rails. Fully certified to NR/L2/TRK/5100/1/WP standards for perimeter control.
As low as £41.88 £50.26
In stock

Quickest Available Delivery: Quickest Available Delivery: 14 Day Delivery Final shipping costs and times are calculated at checkout. Shipping address may affect available delivery methods & times.



HERMEQ’s Network Rail Spec Corner Posts are critical for fencing lines that include turns, angles, or direction changes. Used at junctions between bays, these posts ensure continuity of structural strength and rail alignment across irregular or cornered boundaries. Each unit is built to meet the full NR/L2/TRK/5100/1/WP 2015 specification for rail-sector installations.

Corner posts are manufactured from heavy-duty RSJ steel (102×44×2325mm) and feature a pointed top profile. They support both 45×45×6mm RSA rails and 2.5mm thick W-section steel pales, maintaining bay rigidity and impact resistance across directional transitions. These posts are compatible with all HERMEQ fencing components and are available in galvanised or powder-coated finishes to suit site needs.

  • Corner fitment – Engineered to anchor fencing lines around changes in layout or angles.
  • Installation spacing – Set at 2.75m intervals matching HERMEQ bay geometry.
  • Height variants – Available in 1.8m and 2.4m for perimeter height consistency.
  • Fastening hardware – Compatible with M8 and M12 shear nut fixings.
  • Finish options – Hot-dip galvanised to BS EN ISO 1461; powder coated to RAL if required.

These corner posts provide the structural reinforcement necessary at junction points in fencing layouts. Each unit includes pre-drilled cleats for rail fitting and is designed to connect seamlessly to HERMEQ’s palisade pale runs. With installation ready profiles and certified material specs, they eliminate the need for corner cutting or fabrication on site.

HERMEQ stock a wide-range of Palisade Ultra, Palisade Standard, Palisade Network Rail Spec, Safe Mesh and Domestic Railing options to suit any application.

Need any help? Contact HERMEQ Today.

Contact our team via phone 0800 043 2520, email sales@hermeq.com or use our live chat feature between 8:00am & 17:00pm for help discovering our range.

  • Manufactured to ISO 9001 standards and audited by BSI, CE and BRE to ensure product traceability and compliance.
  • RSJ steel structure prevents torsion and deformation during long-term boundary exposure.
  • Corner cleats accommodate standard HERMEQ RSA rail fittings with no post-modification required.
  • Pre-finished coating options help match site branding or achieve long-life corrosion protection.

These posts are recommended for fencing setups on infrastructure, transport, energy and utilities sites, where directional fencing lines require precise support and compliance with UK rail-sector standards. Corner posts offer the same modular installation speed as HERMEQ’s bay and end posts, enabling seamless transition sections within longer runs or perimeter fencing designs.

Galvanised and optionally powder-coated in RAL6005 or RAL9005, they can be custom finished for colour-coded sites or project branding. Available for next-day shipment in most stock configurations, or fabricated to spec on large-volume contracts.

Where are corner posts used?
At any change in fencing direction, particularly angles or boundaries with turns.

What sizes are available?
Standard heights are 1.8m and 2.4m to match HERMEQ’s bay configurations.

Are corner posts certified for rail-spec fencing?
Yes, all units meet NR/L2/TRK/5100/1/WP 2015 rev A specifications.

Can they be powder coated?
Yes, galvanised base with optional RAL6005, RAL9005, or custom finishes available.
