HERMEQ NorwayRoad Plate Securing Collar
Product Highlights
- Noise-reducing collar - Prevents movement and clatter on safety plates and ground plates.
- Secure road plate fit - Locks through 65–80mm lifting holes for a flush, tight hold.
- Reusable and durable - Strong enough for repeat use on multiple plate installations.
Alternative Products
SKU RP2240
This road plate collar is a reliable fixing accessory designed to secure safety plate systems in place. Used with road plates and ground plates, it prevents rocking and reduces noise. Compatible with lifting hole diameters of 65–80mm, this heavy-duty road plate collar offers a clean finish, fast installation, and long-term performance in all site conditions.
This securing collar is the essential companion for installing and anchoring safety plates. Whether used with road plates, trench covers or ground plates, it locks the corners in place to eliminate movement and minimise trip or noise hazards. Compatible with lifting holes from 65mm to 80mm in diameter, it ensures a tight, safe installation for plates of all sizes.
Supplied as a full unit, each road plate collar includes a 160mm long dual-thread bolt and a protective plastic safety cap. Designed for fast on-site use, the collar can be inserted directly into the road plate’s lifting eye and driven into pre-drilled concrete using standard tools and adaptors. When removal is needed, simply reverse the rotation and extract safely with no wear to the substrate.
- Universal road plate collar – Works with most road plate and safety plate formats including steel and mild steel grades.
- Dual-thread bolt included – Locks securely into concrete and ensures minimal rocking or shifting under weight.
- Noise dampening effect – Eliminates rattle between road plate and surface, improving safety and site comfort.
- Quick install/remove – Requires only a 16mm drill bit and quick-set tool adaptor to secure or release.
- Reusable hardware – High-grade materials withstand multiple project uses without degradation.
Safety plates and road plates need secure anchoring, particularly in high footfall or public traffic zones. The HERMEQ securing collar is a simple, durable solution for fixing plates with precision. Its design addresses both surface stability and health and safety best practice, helping contractors reduce hazards and meet compliance on active sites.
HERMEQ stock a wide-range of Ground Mats, Bog Mats, Trench Covers & Road Plates conforming to all required safety specifications and regulations.
Need any help? Contact HERMEQ Today.
Contact our team via phone 0800 043 2520, email sales@hermeq.com or use our live chat feature between 8:00am & 17:00pm for help discovering our range.
Where and how to use:
- Install by drilling a 16mm hole into concrete or substrate around the road plate.
- Align the securing collar through the road plate lifting hole (65–80mm).
- Use the dual-thread bolt with adaptor to lock into place. Remove by reversing drill direction.
- Plastic safety cap prevents dirt ingress and keeps bolt head clean.
- Reusable across road plates, safety plates and ground plates at multiple sites.
These collars are ideal for applications where movement and vibration must be minimised. Common examples include trench bridging, pedestrian crossings, and vehicle track plates in high-traffic or public environments. By securing the edge of the plate, they prevent tilting or rocking that could result in noise or trip hazards.
All fixings are manufactured from heavy-duty materials for repeated use without wear or loss of integrity. The simple two-part design requires no special tools and integrates easily into any HERMEQ plate system. For full plate installations, use one collar per corner for optimal effect and coverage.
What road plate sizes are compatible with this collar?
It works with all safety plates and road plates that feature lifting holes between 65mm and 80mm.
What tools are needed for installation?
A 16mm drill bit and a standard bolt adaptor are all you need to install or remove the collar.
Can these be reused?
Yes, the collars and bolts are designed for reuse on multiple sites and withstand heavy-duty operations.
Does this work with trench or ground plates?
Yes, it's compatible with all HERMEQ trench covers, ground plates, and road plate formats with suitable hole sizing.
