HERMEQ NorwayEcho Barrier Fence Extension
Product Highlights
- 38.5dB noise reduction - Lab-tested for overhead acoustic control in sensitive environments.
- Rapid deployment - Lightweight barrier installs in under 1 minute with two people.
- Extreme durability - Water, UV, fire and cold-resistant build for rugged site use.
SKU AB113009
A noise absorption and reduction barrier for vertical or overhead noise control. Designed to go on top of fencing or generators taller than 1.5m, this durable and lightweight acoustic barrier fence extension can withstand harsh environments with its fire, water, dust and weather resistant properties. Reducing noise up to 38.5dB and absorbing up to 97% of noise, the extension can be installed within 1 minute by 2 people.
HERMEQ’s acoustic fencing extension delivers vertical and overhead noise control in challenging environments. Designed to sit above fencing or tall equipment (over 1.5m), this unit provides enhanced acoustic coverage for enclosed or elevated areas, effectively protecting workers and the public from unwanted site noise. Reducing sound levels by up to 38.5dB and absorbing up to 97% of noise, it is a powerful addition to your acoustic barrier strategy.
The frame is manufactured from pre-galvanised steel and supports a three-layer barrier construction: a durable PVC outer shell, a high-density composite absorbent core, and a breathable mesh membrane. This unique design prevents water ingress while maximising acoustic absorption. With a total unit weight of only 17.6kg, two-person installation takes less than a minute—ideal for fast-paced construction environments.
- High-performance acoustic control – Reduces noise up to 38.5dB, absorbs 97% of airborne sound.
- Fast vertical deployment – Designed for use above fencing and generators taller than 1.5m.
- Durability in harsh conditions – Fully tested for fire, water, dust, UV and cold resistance.
- Rapid setup – Pre-assembled frame with panel mounted for quick installation by two people.
- Smart multi-layer design – Composite structure balances weight, durability and sound control.
This acoustic noise barrier extension is ideal for urban projects, events, utilities, and high-density worksites with vertical noise concerns. It ensures better sound containment where traditional fencing alone is insufficient, addressing compliance and environmental regulations. HERMEQ stock a wide-range of Crowd Control Barriers, Traffic Barriers, Rope Barriers & Expandable Barriers conforming to all required safety specifications and regulations. Lightweight, easy to use & made with premium quality materials in the UK!
Need any help? Contact HERMEQ Today.
Contact our team via phone 0800 043 2520, email sales@hermeq.com or use our live chat feature between 8:00am & 17:00pm for help discovering our range.
Engineered for industrial conditions, this acoustic fence panel extension combines high-grade performance with long-term durability. Tested under multiple British Standards and real-world site simulations, it performs reliably across all climate zones and worksite types.
- Noise Reduction: 38.5 dB (lab tested)
- Noise Absorption: 97% (lab tested)
- Resistances: Water (IPX6/IPX9), Dust (BSEN 60529), UV (5-year certified), Fire (BS 7837-1996, ASTM E84), Cold (-40°C)
- Dimensions: Height – 502mm (frame), 454mm (mesh); Width – 3500mm
- Weight: Frame – 12kg, Barrier – 5.6kg
The unit’s lightweight construction is reinforced with long-life galvanisation and precision-mounted components, supporting both reuse and rapid deployment. Fire-safe and printable with non-flammable water-based ink, this model is suitable for branded installations across sensitive or high-visibility worksites.
Where should this acoustic fencing extension be used?
This product is designed for use above existing fencing, hoarding, or generators taller than 1.5m where vertical noise reduction is needed.
How is this unit installed?
It arrives pre-mounted to a galvanised steel frame. Two people can install the system in under a minute with minimal tools.
Does it resist harsh weather?
Yes. The barrier is tested for water, dust, UV, fire and cold resistance to ensure performance in varied site conditions.
Can we add logos or colour branding?
Absolutely. The outer PVC layer can be printed with non-flammable water-based ink, allowing for corporate branding on all visible faces.
